Mutoh & STS VJ-628D DTF Drucker

STS DTF Printer

Mutoh STS ValueJet 628D DTF Drucker Grossformat Printer by GOIT

Kurz Info

- max Medienbreite: 630 mm

- 1x DX7 GOLD Druckkopf, 1440dpi

- 5 Farben CMYK WH

- DTF Tinte

- Optionaler Standfuss

Download
Mutoh 628 DE.pdf
Adobe Acrobat Dokument 1.1 MB

Spezifikationen

Print Method Drop-On Demand, Piezo Drive
# of nozzles / # of heads (180 x 8 rows) / 1 head
Ink type DTF
Variable dot Yes
Minimum droplet size 3.5 pl
Print modes 720/540/360 dpi 12 modes +
Color options CMYK + 2W + 2 Cleaning
Maximum resolution 1440 dpi
Head height Low: 12mm / High 2.5mm
Maximum media width 24.8 inches
Maximum print width 24.4 inches
Heating system Pre / Post
Media roll diameter / Core 6′ maximum / Core 3″ or 2″
Stand Optional
Media Auto Cut Standard
RIP software SAI/ White RIP STS – DTF
Power requirements 110/220 Volt
Operating temperature 68°F – 75°F
Operating humidity range 45% -55%
Dimensions (printer) WxDxH 47″ x 17″ x 14″
Dimensions (printer with stand) 47″ x 23″ x 46″
Weight (printer) Printer 70 lbs / Stand 19 lbs
Weight (shipping info) Call for quote
Limited warranty 1 Year
